Structural Engineering Laboratory

Name of the Equipments

100T Capacity Loading Frame including Lateral Supports

Strain Gauges Resistance: 350 ± 0.5Ω


Compression Load Cell-50T

Compression Load Cell-100T

Compression Load Cell-200 T

Vibration Meter

Load Indicator- 5 Channel

Tension Load Cell-100T with 2 hooks

Data Acquisition System (16 Channels)

Electronic Concrete Test Hammer ( Rebound Hammer)

Ultrasonic Pulse Velocity

Hydraulic Jack


Lab Incharge:

 Mr.T.Vijayashanker M.E

Structures lab1   Structures lab2
